ACL Race Series >> ACL Race Series Main bearing set-performance - 3M2204HX-STD

ACL Race Series Main bearing set-performance - 3M2204HX-STD

Part
Thumbnail
Thumbnail
Thumbnail
ACL Race Series logo

ACL Race Series Main bearing set-performance - 3M2204HX-STD

Out Of Stock

Specifications
Material: Race Series (Tri-Metal)
Position: 1,2,3
Std Shaft Diam: 2.0005"/2.0010" (50.813mm/50.825mm)
Oil Clearance: TBA
Maximum Wall: 0.0714" (1.815mm)
Housing Bore: 2.1460"/2.1465" (54.508mm/54.521mm)
Max Length: 1.0050" (25.520mm)
Thrust Washers: 2T2204-STD

Description

(0.001" Extra Oil Clearance)
