Nason >> Nason Piston & Pin Set - 4P1212-0.50

Nason Piston & Pin Set - 4P1212-0.50

Part
Nason logo

Nason Piston & Pin Set - 4P1212-0.50

Out Of Stock

Specifications
Size: 0.50mm Oversize
Ring Set: 5300
Oil Ring Width: 4.00mm
2nd Ring Width: 1.50mm
Top Ring Width: 1.50mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Full Floating
Pin Size: 18.00mm x 61.00mm
Comp Height: 36.00mm - 3.00mm
Length: 69.00mm
Piston Type: Cast
Head Type: Dish Top
Size: 0.50mm / .020"
Std Bore Size: 80.50mm
Piston Set: 4 x Piston & Pins

Description

Round Dish Top
