Nason >> Nason Piston & Pin Set - 4P1286-STD

Nason Piston & Pin Set - 4P1286-STD

Part
Nason logo

Nason Piston & Pin Set - 4P1286-STD

Out Of Stock

Specifications
2nd Ring Width: 1.50mm
Oil Ring Width: 2.50mm
Ring Set: 2C4174
Top Ring Width: 1.20mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 21.00mm x 61.50mm
Comp Height: 27.30mm - 6.50mm
Length: 50.30mm
Piston Type: Cast
Head Type: Dish Top
Std Bore Size: 87.50mm
Piston Set: 4 x Piston & Pins

Description

Anodized Head , Top & 2nd Ring Lands
