Nason >> Nason Piston & Pin Set - 4P1402-0.50

Nason Piston & Pin Set - 4P1402-0.50

Part
Nason logo

Nason Piston & Pin Set - 4P1402-0.50

Out Of Stock

Specifications
Size: 0.50mm Oversize
Ring Set: 2C5389
Oil Ring Width: 2.00mm
2nd Ring Width: 1.20mm
Top Ring Width: 1.20mm
Piston to Bore: See Label on Box
Skirt Coating: Yes
Pin Type: Press Fit
Pin Size: 18.00mm x 47.50mm
Comp Height: 30.80mm + 0.20mm
Length: 54.00mm
Piston Type: Cast
Head Type: Dome Top with 1 Valve Reliefs
Size: 0.50mm / .020"
Std Bore Size: 71.50mm
Piston Set: 4 x Piston & Pins
