Chevrolet >> Corvette >> C3 >> 5.4 Litre V8 327 OHV 16v >> 01/1968 - 12/1968 2 Door Coupe >> Nason Cylinder head - assembled

Nason Cylinder head - assembled Fits Chevrolet Corvette C3 Coupe [01/1968 to 12/1968] (5.4L 327 V8 OHV CARB)

Part
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Nason logo

Nason Cylinder head - assembled

Fitment Information:

Angled spark plug type Assembled - Alloy Performance

$1,406.59 Each / Full Set (x2): $2,813.18

Specifications
Combustion Chamber Volume: 64cc
Intake Port Volume: 195cc
Intake Port Size H x W: 2.090" x 1.161"
Exhaust Port Volume: 74cc
Exhaust Port Size H x W: 1.401" x 1.421"
Spark Plug Style: Angle
Spark Plug Type: 14mm x 1.25mm x 19mm
Valve Angle: 23 Degree
Valve Diameter - Inlet: 2.020"
Valve Diameter - Exhaust: 1.600"
Valve Material: Stainless Steel
Valve Spring Diameter: 1.437"
Valve Spring Installed Height: 1.800"
Valve Spring Pressure @ 1.800": 105lbs
Valve Spring Pressure @ 1.225": 300lbs
Valve Spring Maximum Lift: 0.575"
Valve Lock Type: 7 Degree
Valve Stem Seal Material: Viton
Rocker Stud Size: 7/16"
Guide Plate Pushrod Size: 5/16"
Intake Gasket - Felpro: 1205
Exhaust Gasket - Felpro: 1404

Tick This part will fit the following Vehicles:

Chevrolet Corvette C1 (5.4 Litre V8 327 OHV 16v):
  • RWD Convertible 2 Door [01/1962 to 12/1962] With Auto or Manual Transmission
Chevrolet Corvette C2 (5.4 Litre V8 327 OHV 16v):
  • RWD Convertible 2 Door [01/1962 to 12/1964] With Auto or Manual Transmission
  • RWD Convertible 2 Door [01/1965 to 12/1968] With Auto or Manual Transmission
  • RWD Coupe 2 Door [01/1965 to 12/1968] With Auto or Manual Transmission
Chevrolet Corvette C3 (5.4 Litre V8 327 OHV 16v):
  • RWD Convertible 2 Door [01/1968 to 12/1968] With Auto or Manual Transmission
  • RWD Coupe 2 Door [01/1968 to 12/1968] With Auto or Manual Transmission
Chevrolet Impala (5.4 Litre V8 327 OHV 16v):
  • RWD Hardtop 4 Door [01/1962 to 12/1969] With Auto or Manual Transmission
  • RWD Wagon 4 Door [01/1962 to 12/1969] With Auto or Manual Transmission

Description

Angled spark plug type
