| Specifications |
| Max Overall Length: |
0.6693in / 17mm |
| Semi-finished: |
N |
| Min Vertical Oil Clearance: |
0.0005in / 0.013mm |
| Max Vertical Oil Clearance: |
0.0045in / 0.114mm |
| Material: |
F23 |
| Camshaft Bearing (c): |
5616 |
| OE Part Number 1: |
C20Z-6267B |
| Manufacturer: |
ACL |
| Min Std Shaft Size: |
2.0655in / 52.464mm |
| Max Std Shaft Size: |
2.0665in / 52.489mm |
| Min Std Tunnel Size: |
2.189in / 55.601mm |
| Max Std Tunnel Size: |
2.19in / 55.626mm |
| Max Wall At Crown: |
0.0608in / 1.544mm |
| Max Overall Length: |
0.6701in / 17.02mm |
| Semi-finished: |
N |
| Min Vertical Oil Clearance: |
0.001in / 0.025mm |
| Max Vertical Oil Clearance: |
0.005in / 0.127mm |
| Material: |
F23 |
| Camshaft Bearing (c): |
5617 |
| OE Part Number 1: |
C20Z-6262B |
| Manufacturer: |
ACL |
| Min Std Shaft Size: |
2.0505in / 52.083mm |
| Max Std Shaft Size: |
2.0515in / 52.108mm |
| Min Std Tunnel Size: |
2.174in / 55.22mm |
| Max Std Tunnel Size: |
2.175in / 55.245mm |
| Max Wall At Crown: |
0.0608in / 1.544mm |
| Max Overall Length: |
0.6701in / 17.02mm |
| Semi-finished: |
N |
| Max Wall At Crown: |
0.0619in / 1.572mm |
| Max Std Tunnel Size: |
2.2505in / 57.163mm |
| Min Std Tunnel Size: |
2.2495in / 57.137mm |
| Max Std Shaft Size: |
2.125in / 53.975mm |
| Min Std Shaft Size: |
2.1240in / 53.95mm |
| Manufacturer: |
ACL |
| OE Part Number 1: |
D0AZ-6261B |
| Camshaft Bearing (c): |
5696 |
| Material: |
F23 |
| Max Vertical Oil Clearance: |
0.005in / 0.127mm |
| Min Vertical Oil Clearance: |
0.001in / 0.025mm |
| Semi-finished: |
N |
| Max Overall Length: |
0.6701in / 17.02mm |
| Max Wall At Crown: |
0.0608in / 1.544mm |
| Max Std Tunnel Size: |
2.145in / 54.483mm |
| Min Std Tunnel Size: |
2.144in / 54.458mm |
| Max Std Shaft Size: |
2.0215in / 51.346mm |
| Min Std Shaft Size: |
2.0205in / 51.321mm |
| Manufacturer: |
ACL |
| OE Part Number 1: |
C20Z-6263A |
| Camshaft Bearing (c): |
5619 |
| Manufacturer: |
ACL |
| Brand: |
ACL |
| Camshaft Bearing Set: |
5C5696 |
| Min Vertical Oil Clearance: |
0.001in / 0.025mm |
| Max Vertical Oil Clearance: |
0.005in / 0.127mm |
| Material: |
F23 |
| Camshaft Bearing (c): |
5618 |
| OE Part Number 1: |
C20Z-6207B |
| Manufacturer: |
ACL |
| Min Std Shaft Size: |
2.0355in / 51.702mm |
| Max Std Shaft Size: |
2.0365in / 51.727mm |
| Min Std Tunnel Size: |
2.1590in / 54.839mm |
| Max Std Tunnel Size: |
2.16in / 54.864mm |
| Max Wall At Crown: |
0.0608in / 1.544mm |
| Max Overall Length: |
0.6701in / 17.02mm |
| Semi-finished: |
N |
| Min Vertical Oil Clearance: |
0.0010in / 0.025mm |
| Max Vertical Oil Clearance: |
0.005in / 0.127mm |
| Material: |
F23 |
