Ford >> Galaxie >> (No Series) >> 4.7 Litre V8 289 WINDSOR OHV 16v >> 05/1964 - 05/1966 4 Door Sedan >> Nason Cylinder head - bare

Nason Cylinder head - bare Fits Ford Galaxie Sedan [05/1964 to 05/1966] (4.7L 289 WINDSOR V8 OHV CARB)

Part
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Nason logo

Nason Cylinder head - bare

$852.51

Specifications
Combustion Chamber Volume: 61cc
Intake Runner Volume: 185cc
Intake Port Size H x W: 2.020" x 1.126"
Exhaust Runner Volume: 65cc
Exhaust Port Size H x W: 1.362" x 1.354"
Spark Plug Angle: Angle
Intake Valve Size: 2.020"/51.30mm
Exhaust Valve Size: 1.600"/40.64mm
Valve Length: Chev Small Block
Valve Guide Seal Diameter: 0.531"/13.48mm
Valve Guide Material: Manganese Bronze
Maximum Valve Spring Diameter: 1.550"/39.37mm

Tick This part will fit the following Vehicles:

Ford Galaxie (4.7 Litre V8 289 WINDSOR OHV 16v):
  • RWD Sedan 4 Door [05/1964 to 05/1966] 149KW With Auto Transmission
  • RWD Sedan 4 Door [05/1964 to 05/1966] 149KW With Auto Transmission
  • RWD Sedan 4 Door [06/1966 to 02/1968] 145KW With Auto Transmission
  • RWD Sedan 4 Door [06/1966 to 02/1968] 145KW With Auto Transmission
Ford Galaxie (4.9 Litre V8 302 WINDSOR OHV 16v):
  • RWD Sedan 4 Door [03/1968 to 01/1970] 157KW With Auto Transmission

Description

Bare Head - Alloy Performance - 61cc Chamber

Spark Plugs, Thread = 14mm x 1.25mm, Seat = Gasket, Reach = 19mm

Requires Screw In Rocker Studs & Guide Plates

Flow Data @ 28"(CFM) With 2.020" & 1.600" Valves

@.200" = 114

@.300" = 167

@.400" = 218

@.500" = 236

@.600" = 251

Exhaust

@.200" = 102

@.300" = 143

@.400" = 152

@.500" = 152

@.600" = 152
