Holden >> Crewman >> VZ >> 6.0 Litre V8 L76 OHV 16v >> Cross 8 02/2006 - 07/2006 4 Door Ute >> Nason Cylinder head - assembled

Nason Cylinder head - assembled Fits Holden Crewman VZ Cross 8 Ute [02/2006 to 07/2006] (6.0L L76 V8 OHV MPFI)

Part
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Nason logo

Nason Cylinder head - assembled

Fitment Information:

Assembled

Out Of Stock

Specifications
Combustion Chamber Volume: 68cc
Intake Runner Volume: 262cc
Intake Port Size H x W: 2.585" x 1.185"/65.66mm x 30.10mm
Exhaust Runner Volume: 85cc
Exhaust Port Size H x W: 1.46" x 1.60"/37.08mm x 40.64mm D Port
Intake Valve Size: 2.165"/54.99mm
Exhaust Valve Size: 1.589"/40.38mm
Valve Length: Standard Length
Valve Guide Seal Diameter: 0.502"/12.75mm
Valve Guide Material: Cast Iron
Maximum Valve Spring Diameter: 1.340"/34.04mm

Tick This part will fit the following Vehicles:

Holden Crewman VZ (6.0 Litre V8 L76 OHV 16v):
  • Cross 8 4WD Ute 4 Door [02/2006 to 07/2006] 260KW With Auto Transmission
  • SS, SS Thunder RWD Ute 4 Door [02/2006 to 07/2006] 260KW With Auto or Manual Transmission
Holden Crewman VZ (6.0 Litre V8 L98 OHV 16v):
  • SS RWD Ute 4 Door [08/2006 to 09/2007] 270KW With Auto or Manual Transmission

Description

Assembled Head - Suits Engines With Rectangle Intake Ports

Includes :

Cylinder Head

Valves Inlet & Exhaust

Valve Springs

Valve Spring Retainers

Valve Spring Seats

Valve Collets

Valve Stem Seals

Flow Data @ 28"(CFM) With 2.165" & 1.600" Valves

Intake

@.200" = 132

@.300" = 200

@.400" = 256

@.500" = 289

@.600" = 302

@.700" = 314

Exhaust

@.200" = 106

@.300" = 150

@.400" = 181

@.500" = 202

@.600" = 213

@.700" = 219
