Holden >> Monaro >> HG >> 5.7 Litre V8 350 OHV 16v >> GTS 350 09/1970 - 07/1971 2 Door Coupe >> Nason Cylinder head - assembled

Nason Cylinder head - assembled Fits Holden Monaro HG GTS 350 Coupe [09/1970 to 07/1971] (5.7L 350 V8 OHV CARB)

Part
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Thumbnail
Nason logo

Nason Cylinder head - assembled

Fitment Information:

Angled spark plug type Assembled - Alloy Performance

$1,406.59 Each / Full Set (x2): $2,813.18

Specifications
Combustion Chamber Volume: 64cc
Intake Port Volume: 195cc
Intake Port Size H x W: 2.090" x 1.161"
Exhaust Port Volume: 74cc
Exhaust Port Size H x W: 1.401" x 1.421"
Spark Plug Style: Angle
Spark Plug Type: 14mm x 1.25mm x 19mm
Valve Angle: 23 Degree
Valve Diameter - Inlet: 2.020"
Valve Diameter - Exhaust: 1.600"
Valve Material: Stainless Steel
Valve Spring Diameter: 1.437"
Valve Spring Installed Height: 1.800"
Valve Spring Pressure @ 1.800": 105lbs
Valve Spring Pressure @ 1.225": 300lbs
Valve Spring Maximum Lift: 0.575"
Valve Lock Type: 7 Degree
Valve Stem Seal Material: Viton
Rocker Stud Size: 7/16"
Guide Plate Pushrod Size: 5/16"
Intake Gasket - Felpro: 1205
Exhaust Gasket - Felpro: 1404

Tick This part will fit the following Vehicles:

Holden Monaro HG (5.7 Litre V8 350 OHV 16v):
  • GTS 350 RWD Coupe 2 Door [09/1970 to 07/1971] 224KW With Manual Transmission
  • GTS 350 RWD Coupe 2 Door [09/1970 to 07/1971] 205KW With Auto Transmission
Holden Monaro HQ (5.7 Litre V8 350 OHV 16v):
  • GTS RWD Sedan 4 Door [04/1973 to 10/1974] 205KW With Auto or Manual Transmission
  • GTS 350 RWD Coupe 2 Door [07/1971 to 10/1974] 205KW With Auto or Manual Transmission
  • LS RWD Coupe 2 Door [07/1971 to 10/1974] 205KW With Auto or Manual Transmission
Holden Monaro HT (5.7 Litre V8 350 OHV 16v):
  • GTS 350 RWD Coupe 2 Door [06/1969 to 07/1970] 205KW With Auto Transmission
  • GTS 350 RWD 2 Door [06/1969 to 07/1970] 300KW With Manual Transmission
Holden Statesman HQ (5.7 Litre V8 350 OHV 16v):
  • RWD Sedan 4 Door [07/1971 to 10/1974] 205KW With Auto or Manual Transmission
  • De Ville RWD Sedan 4 Door [07/1971 to 10/1974] 205KW With Auto Transmission

Description

Angled spark plug type
