Nason Piston & pin set Fits Mazda 121 DW Metro DW5W Hatchback [10/1996 to 12/2002] (1.5L B5 4 Cyl SOHC SPFI)

Name: Nason Piston & pin set Fits Mazda 121 DW Metro DW5W Hatchback [10/1996 to 12/2002] (1.5L B5 4 Cyl SOHC SPFI)
Brand: Nason
SKU: TE1324416
Availability: OutOfStock

Nason Piston & pin set

Fitment Information:

Nason, STD Size

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	78.00mm
Size:	Std
Head Type:	Dish Top with 4 Valve Relief
Piston Type:	Cast
Length:	63.00mm
Comp Height:	32.00mm - 0.90mm
Pin Size:	20.00mm x 61.00mm
Pin Type:	Press Fit
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.50mm
2nd Ring Width:	1.50mm
Oil Ring Width:	3.00mm
Ring Set:	2C4737 or 4737

This part will fit the following Vehicles:

Mazda 121 DB (1.5 Litre 4 Cyl B5 SOHC 8v):

DB5P FWD Sedan 4 Door [01/1994 to 12/1996] 62KW With Auto or Manual Transmission

Mazda 121 DW (1.5 Litre 4 Cyl B5 SOHC 8v):

Metro DW5W FWD Hatchback 4 Door [10/1996 to 12/2002] 64KW With Auto or Manual Transmission
