Nason Piston & pin set Fits Mazda B2600 UN Bravo DX Freestyle UNY06 Ute [11/2002 to 11/2006] (2.6L G6 4 Cyl SOHC SPFI)

Name: Nason Piston & pin set Fits Mazda B2600 UN Bravo DX Freestyle UNY06 Ute [11/2002 to 11/2006] (2.6L G6 4 Cyl SOHC SPFI)
Brand: Nason
SKU: TE1320689
Availability: OutOfStock

Nason Piston & pin set

Fitment Information:

Nason, 1.50mm Oversize

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	92.00mm
Size:	1.50mm / .060"
Head Type:	Dish Top
Piston Type:	Cast
Length:	74.50mm
Comp Height:	36.50mm - 9.50mm
Pin Size:	23.00mm x 63.00mm
Pin Type:	Press Fit
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.50mm
2nd Ring Width:	1.50mm
Oil Ring Width:	4.00mm
Ring Set:	2M4216 or 4216
Size:	1.50mm Oversize

This part will fit the following Vehicles:

Mazda B2600 UF (2.6 Litre 4 Cyl G6 SOHC 12v):

Bravo UFY06 4WD Ute 2 Door [11/1991 to 02/1999] 92KW With Manual Transmission
Bravo UFY06 RWD Ute 2 Door [11/1991 to 02/1999] 92KW With Auto or Manual Transmission
Bravo UFY06 4WD Ute 4 Door [11/1991 to 02/1999] 92KW With Manual Transmission
Bravo UFY06 RWD Ute 4 Door [11/1991 to 02/1999] 92KW With Auto or Manual Transmission

Mazda B2600 UN (2.6 Litre 4 Cyl G6 SOHC 12v):

Bravo DX Freestyle UNY06 RWD Ute 4 Door [11/2002 to 11/2006] 92KW With Auto or Manual Transmission
Bravo UNY06 4WD Ute 2 Door [02/1999 to 12/2002] 92KW With Auto or Manual Transmission
Bravo UNY06 RWD Ute 2 Door [02/1999 to 11/2006] 92KW With Auto or Manual Transmission
Bravo UNY06 4WD Ute 4 Door [02/1999 to 11/2006] 92KW With Auto or Manual Transmission
Bravo UNY06 RWD Ute 4 Door [02/1999 to 11/2006] 92KW With Auto or Manual Transmission
