Mitsubishi
>>
Starwagon
>>
WA
>>
2.0 Litre 4 Cyl 4G63 SOHC 8v
>>
GL SWB PA3W 06/1998 - 09/2003 3 Door Wagon
>> Nason Conrod bearing set
Nason Conrod bearing set Fits Mitsubishi Starwagon WA GL SWB PA3W Wagon [06/1998 to 09/2003] (2.0L 4G63 4 Cyl SOHC MPFI)
Nason Conrod bearing set
Out Of Stock
Specifications
Conrod Bearing Set:
4B1185N
Brand:
Nason
Manufacturer:
TDC
Conrod Bearing (c):
1185A
Half Type:
Identical Halves
OE Part Number 1:
MD195939
Manufacturer:
TDC
Min Std Shaft Size:
1.7709in / 44.981mm
Max Std Shaft Size:
1.7715in / 44.996mm
Min Std Tunnel Size:
1.8897in / 47.998mm
Max Std Tunnel Size:
1.8905in / 48.019mm
Max Wall At Crown:
0.0588in / 1.493mm
Max Overall Length:
0.8307in / 21.1mm
Min Vertical Oil Clearance:
0.0006in / 0.016mm
Max Vertical Oil Clearance:
0.0031in / 0.078mm
Material:
F810
Size:
21mm Wide
This part will fit the following Vehicles:
Mitsubishi Starwagon
WA
(2.0 Litre 4 Cyl 4G63 SOHC 8v):
GL SWB L400 WA1M35 RWD Wagon 3 Door [06/1994 to 05/1998] 78KW With Manual Transmission
GL SWB L400 WA2M35 RWD Wagon 3 Door [06/1994 to 05/1998] 78KW With Auto Transmission
GL SWB PA3W RWD Wagon 3 Door [06/1994 to 05/1998] 78KW With Auto Transmission
GL SWB PA3W RWD Wagon 3 Door [06/1998 to 09/2003] 85KW With Auto Transmission
GL SWB PA3W RWD Wagon 3 Door [06/1998 to 10/2003] 85KW With Manual Transmission
Description
4B1185N Is 21.0mm Wide
