Toyota >> Hiace >> RZH101R >> 2.4 Litre 4 Cyl 2RZ-E SOHC 8v >> 08/1989 - 08/2002 3 Door Van >> Nason Piston & Pin Set

Nason Piston & Pin Set Fits Toyota Hiace RZH101R Van [08/1989 to 08/2002] (2.4L 2RZ-E 4 Cyl SOHC MPFI)

Part
Nason logo

Nason Piston & Pin Set

$283.14

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 95.00mm
Size: 0.50mm / .020"
Head Type: Dish Top with 2 Valve Reliefs
Piston Type: Cast
Length: 58.10mm
Comp Height: 35.20mm - 6.00mm
Pin Size: 24.00mm x 70.00mm
Pin Type: Full Floating
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.75mm
2nd Ring Width: 1.50mm
Oil Ring Width: 4.00mm
Ring Set: 2C4687 or 4687
Size: 0.50mm Oversize

Tick This part will fit the following Vehicles:

Toyota Hiace RCH22R (2.4 Litre 4 Cyl 2RZ-E SOHC 8v):
  • SBV RWD Van 3 Door [10/1999 to 02/2005] 88KW With Manual Transmission
Toyota Hiace RZH101R (2.4 Litre 4 Cyl 2RZ-E SOHC 8v):
  • RWD Van 3 Door [08/1989 to 08/2002] 89KW With Auto Transmission
Toyota Hiace RZH103R (2.4 Litre 4 Cyl 2RZ-E SOHC 8v):
  • RZH106 RWD Van 3 Door [09/1998 to 08/2004] 85KW With Auto or Manual Transmission
  • SBV RCH12 RWD Van 3 Door [10/1995 to 02/2005] 88KW With Manual Transmission
Toyota Hiace RZH113R (2.4 Litre 4 Cyl 2RZ-E SOHC 8v):
  • RZH111 RWD Van 3 Door [09/1998 to 02/2005] 85KW With Auto or Manual Transmission
Toyota Hiace RZH125R (2.4 Litre 4 Cyl 2RZ-E SOHC 8v):
  • RWD Van 3 Door [08/1998 to 08/2003] With Auto Transmission
  • RWD Van 3 Door [09/1998 to 02/2005] 85KW With Auto or Manual Transmission
Toyota Hiace RZH133R (2.4 Litre 4 Cyl 2RZ-E SOHC 8v):
  • RWD 3 Door [08/1995 to 07/1999] With Auto Transmission

Description

Nason Piston & Pin Set 0.50 Oversize – Performance Redefined

Elevate your engine's performance with the Nason Piston & Pin Set 0.50 Oversize, designed specifically for Toyota Hiace models RZH125R and RZH133R featuring a robust 2.4L engine. Crafted from high-quality cast materials, this piston set guarantees durability while optimizing power output for a smooth, reliable ride.

Key Features:

  • Complete Set: Includes 4 precision-engineered pistons and pins to ensure a seamless replacement and hassle-free installation.
  • Standard Bore Size: Designed for a 95.00mm bore, this oversize option (0.50mm / .020\") allows for efficient engine operation and enhanced performance.
  • Innovative Head Design: Each piston features a dish top with 2 valve reliefs to accommodate your engine's specifications for optimal combustion.
  • Key Specifications:
  • Length: 58.10mm
  • Compression Height: 35.20mm - 6.00mm
  • Pin Size: 24.00mm x 70.00mm (Full Floating)
  • Top Ring Width: 1.75mm
  • 2nd Ring Width: 1.50mm
  • Oil Ring Width: 4.00mm
  • Ring Set Compatibility: 2C4687 or 4687

Why Choose Nason?

Nason is synonymous with quality and reliability in the automotive industry. Each piston in this set is meticulously crafted to meet strict industry standards, delivering exceptional performance under varying driving conditions. Whether you’re engaged in everyday commuting or heavy-duty applications, trust Nason for unparalleled performance and longevity.

Upgrade your Toyota Hiace with the Nason Piston & Pin Set 0.50 Oversize today and experience the difference in power, efficiency, and durability. Your engine deserves the best—choose Nason for superior performance on the road!
