ACL Race Series >> ACL Race Series Main bearing set-performance - 5M7298HXX-STD

ACL Race Series Main bearing set-performance - 5M7298HXX-STD

Part
Thumbnail
Thumbnail
Thumbnail
ACL Race Series logo

ACL Race Series Main bearing set-performance - 5M7298HXX-STD

Out Of Stock

Specifications
Material: Race Series (Tri-Metal)
Position: 1,2,4,5
Std Shaft Diam: 2.5588"/2.5593" (64.993mm/65.007mm)
Oil Clearance: TBA
Maximum Wall: 0.0952" (2.417mm)
Housing Bore: 2.7509"/2.7515" (69.873mm/69.887mm)
Max Length: 0.8050" (20.450mm)
Position: 3
Std Shaft Diam: 2.5588"/2.5593" (64.993mm/65.007mm)
Oil Clearance: TBA
Maximum Wall: 0.0952" (2.417mm)
Housing Bore: 2.7509"/2.7515" (69.873mm/69.887mm)
Max Length: 1.0280" (26.100mm)

Description

(0.002" Extra Oil Clearance)
