Nason >> Nason Liner assembly kit - SAI4HJ1

Nason Liner assembly kit - SAI4HJ1

Part
Nason logo

Nason Liner assembly kit - SAI4HJ1

Out Of Stock

Specifications
Piston Set: 4 x Pistons, Pins & Rings
Std Bore Size: 115.00mm
Size: STD
Head Type: Dish top
Piston Type: Cast
Length: 122.50mm
Comp Height: 68.70mm - 24.00mm - 9.50mm
Combustion Bowl OD: 53.00mm
Pin Size: 36.00mm x 79.00mm
Pin Type: Full Floating
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 3.00mm Half Keystone
2nd Ring Width: 2.50mm
Oil Ring Width: 4.00mm
Liner Grade: Finished- Phosphated
Liner Length: 200.00mm
Liner OD: 118.00mm
Flange Diameter: 123.70mm
Flange Depth: 6.00mm

Description

Includes Finished- Phosphated Liner

Alfin insert

Oil Gallery Cooling
