Nason >> Nason Liner assembly kit - SANTD42L-A-SF

Nason Liner assembly kit - SANTD42L-A-SF

Part
Nason logo

Nason Liner assembly kit - SANTD42L-A-SF

Out Of Stock

Specifications
Liner kit: 6 x Liners, Pistons, Pins & Rings
Std Bore Size: 96.00mm
Size: STD
Head Type: Flat top
Piston Type: Cast
Length: 86.00mm
Comp Height: 50.30mm - 0.50mm - 1.70mm
Pin Size: 30.00mm x 74.00mm
Pin Type: Full Floating
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 2.50mm
2nd Ring Width: 2.00mm
Oil Ring Width: 3.00mm
Liner Grade: Semi Finished
Liner Length: 164.00mm
Liner OD: 99.00mm
Flange Diameter: 105.00mm
Flange Depth: 5.00mm

Description

30mm Gudgeon pin

Alfin insert
