Nason Liner assembly kit - SATN04CT

Specifications
Liner Kit:	4 x Pistons, Pins, Rings, Liners & Pin Bushes
STD Bore Size:	104.00mm
Piston Size:	STD
Piston Head Type:	Dish top
Piston Type:	Cast
Piston Length:	100.00mm
Piston Comp Height:	60.20mm - 8.50mm - 18.80mm
Combustion Bowl OD:	59.30mm
Piston Pin Size:	37.00mm x 85.00mm
Piston Pin Type:	Full Floating
Piston Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	2.50mm
2nd Ring Width:	2.00mm
Oil Ring Width:	4.00mm
Piston:	Alfin inserts, Oil gallery cooling, MOS2 coated skirts
Liner Type:	B Grade
Liner Lenght:	200.00mm
Liner OD:	107.00mm
Liner Flange OD:	112.00mm
Liner Flange Depth:	8.00mm

Description

Includes B grade liners- See Notes
