Nason Piston & pin set - 3P1008-1.00

Part

Nason Piston & pin set - 3P1008-1.00

Out Of Stock

Specifications
Piston Set:	3 x Piston & Pins
Std Bore Size:	72.00mm
Size:	1.00mm / .040"
Head Type:	Dish Top 4 Valve Reliefs
Piston Type:	Cast
Length:	50.60mm
Comp Height:	28.50mm - 6.80mm
Pin Size:	18.00mm X 52.00mm
Pin Type:	Press Fit
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.20mm
2nd Ring Width:	1.20mm
Oil Ring Width:	2.50mm
Ring Set:	2C5189

Description

Anodized Head

Replaces 3MKRY2898
