Nason >> Nason Piston & pin set - 4P1000-1.00

Nason Piston & pin set - 4P1000-1.00

Part
Nason logo

Nason Piston & pin set - 4P1000-1.00

$276.70

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 86.00mm
Size: 1.00mm / .040"
Head Type: Dome Top 4 Valve Reliefs
Piston Type: Cast
Length: 51.50mm
Comp Height: 27.50mm + 1.00mm
Pin Size: 21.00mm x 58.00mm
Pin Type: Press Fit
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.20mm
Oil Ring Width: 2.00mm
Ring Set: 2C4835
Size: 1.00mm Oversize
