Nason Piston & pin set - 4P1000-STD

Part

Nason Piston & pin set - 4P1000-STD

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	86.00mm
Size:	Std
Head Type:	Dome Top 4 Valve Reliefs
Piston Type:	Cast
Length:	51.50mm
Comp Height:	27.50mm + 1.00mm
Pin Diam:	21.00mm x 58.00mm
Pin Type:	Press Fit
Skirt Coating:	Yes
Piston to Bore:	See Label on Box
Top Ring Width:	1.20mm
2nd Ring Width:	1.20mm
Oil Ring Width:	2.00mm
Ring Set:	2C4835
