Nason >> Nason Piston & pin set - 4P1015-1.50

Nason Piston & pin set - 4P1015-1.50

Part
Nason logo

Nason Piston & pin set - 4P1015-1.50

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 82.00mm
Size: 1.50mm / .060"
Head Type: Dome Top
Piston Type: Cast
Length: 80.50mm
Comp Height: 37.00mm + 0.50mm
Pin Size: 22.00mm x 69.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 2.00mm
2nd Ring Width: 2.00mm
Oil Ring Width: 4.00mm
Ring Set: 2M4294 or 4294

Description

Replaces 4KRY2586
