Nason >> Nason Piston & Pin Set - 4P1035-1.00

Nason Piston & Pin Set - 4P1035-1.00

Part
Nason logo

Nason Piston & Pin Set - 4P1035-1.00

Out Of Stock

Specifications
Size: 1.00mm Oversize
Ring Set: 2C6175 or 6175
Oil Ring Width: 4.00mm
2nd Ring Width: 2.00mm
Top Ring Width: 1.50mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 20.00mm x 65.00mm
Comp Height: 29.00mm + 0.80mm
Length: 61.70mm
Piston Type: Cast
Head Type: Dome Top with 1 Valve Relief
Size: 1.00mm / .040"
Std Bore Size: 77.00mm
Piston Set: 4 x Piston & Pins
