Nason >> Nason Piston & pin set - 4P1037-0.50

Nason Piston & pin set - 4P1037-0.50

Part
Nason logo

Nason Piston & pin set - 4P1037-0.50

$267.05

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 92.00mm
Size: 0.50mm / .020"
Head Type: Dish Top
Piston Type: Cast
Length: 74.50mm
Comp Height: 36.50mm - 9.50mm
Pin Size: 23.00mm x 63.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.50mm
2nd Ring Width: 1.50mm
Oil Ring Width: 4.00mm
Ring Set: 2M4216 or 4216
Size: 0.50mm Oversize
