Nason Piston & pin set - 4P1037-1.00

Part

Nason Piston & pin set - 4P1037-1.00

$267.05

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	92.00mm
Size:	1.00mm / .040"
Head Type:	Dish Top
Piston Type:	Cast
Length:	74.50mm
Comp Height:	36.50mm - 9.50mm
Pin Size:	23.00mm x 63.00mm
Pin Type:	Press Fit
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.50mm
2nd Ring Width:	1.50mm
Oil Ring Width:	4.00mm
Ring Set:	2M4216 or 4216
Size:	1.00mm Oversize
