Nason >> Nason Piston & pin set - 4P1038-1.00

Nason Piston & pin set - 4P1038-1.00

Part
Nason logo

Nason Piston & pin set - 4P1038-1.00

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 78.00mm
Size: 1.00mm / .040"
Head Type: Dish Top with 3 Valve Reliefs
Piston Type: Cast
Length: 63.00mm
Comp Height: 31.90mm - 4.30mm
Pin Size: 20.00mm x 65.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.50mm
2nd Ring Width: 1.50mm
Oil Ring Width: 4.00mm
Ring Set: 2M4265 or 4265
Size: 1.00mm Oversize
