Nason >> Nason Piston & pin set - 4P1041-0.50

Nason Piston & pin set - 4P1041-0.50

Part
Nason logo

Nason Piston & pin set - 4P1041-0.50

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 76.00mm
Size: 0.50mm / .020"
Head Type: Dish Top
Piston Type: Cast
Length: 53.50mm
Comp Height: 29.10mm - 5.00mm
Pin Size: 19.00mm x 52.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.20mm
Oil Ring Width: 2.50mm
Ring Set: 2C5182

Description

Anodized Head, Top & 2nd Ring Lands

Replaces 4KRY8090
