Nason >> Nason Piston & pin set - 4P1042-0.50

Nason Piston & pin set - 4P1042-0.50

Part
Nason logo

Nason Piston & pin set - 4P1042-0.50

$189.83

Specifications
Size: 0.50mm Oversize
Ring Set: 2C4113
Oil Ring Width: 1.50mm
2nd Ring Width: 1.00mm
Top Ring Width: 1.00mm
Piston to Bore: See Label on Box
Skirt Coating: Yes
Pin Type: Full Floating
Pin Size: 20.00mm x 50.00mm
Comp Height: 31.10mm - 6.40mm
Length: 50.20mm
Piston Type: Cast
Head Type: Dish Top
Size: 0.50mm / .020"
Std Bore Size: 80.50mm
Piston Set: 4 x Piston & Pins

Description

Anodized Head, Top & 2nd Ring Lands
