Nason >> Nason Piston & pin set - 4P1046-STD

Nason Piston & pin set - 4P1046-STD

Part
Nason logo

Nason Piston & pin set - 4P1046-STD

Out Of Stock

Specifications
Ring Set: 2C4875
Oil Ring Width: 3.00mm
2nd Ring Width: 1.50mm
Top Ring Width: 1.20mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 19.00mm x 58.00mm
Comp Height: 30.20mm + 0.50mm
Length: 60.70mm
Piston Type: Cast
Head Type: Dome Top
Std Bore Size: 76.00mm
Piston Set: 4 x Piston & Pins
