Nason >> Nason Piston & pin set - 4P1046-STD

Nason Piston & pin set - 4P1046-STD

Part
Nason logo

Nason Piston & pin set - 4P1046-STD

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 76.00mm
Size: Std
Head Type: Dome Top
Piston Type: Cast
Length: 60.70mm
Comp Height: 30.20mm + 0.50mm
Pin Size: 19.00mm x 58.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.50mm
Oil Ring Width: 3.00mm
Ring Set: 2C4875

Description

Replaces 4MKRY2931
