Nason >> Nason Piston & pin set - 4P1059-1.00

Nason Piston & pin set - 4P1059-1.00

Part
Nason logo

Nason Piston & pin set - 4P1059-1.00

$107.93

Specifications
Size: 1.00mm Oversize
Ring Set: 2C4659
Oil Ring Width: 2.80mm
2nd Ring Width: 1.50mm
Top Ring Width: 1.50mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Full Floating
Pin Size: 19.00mm x 52.00mm
Comp Height: 29.50mm - 4.80mm
Length: 54.00mm
Piston Type: Cast
Head Type: Dish Top
Size: 1.00mm / .040"
Std Bore Size: 76.00mm
Piston Set: 4 x Piston & Pins
