Nason >> Nason Piston & pin set - 4P1060-0.50

Nason Piston & pin set - 4P1060-0.50

Part
Nason logo

Nason Piston & pin set - 4P1060-0.50

$154.24

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 82.00mm
Size: 0.50mm / .020"
Head Type: Dome Top with 1 Valve Reliefs
Piston Type: Cast
Length: 60.90mm
Comp Height: 31.00mm + 2.20mm
Pin Size: 20.00mm x 59.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.20mm
Oil Ring Width: 2.50mm
Ring Set: 2C4943
Size: 0.50mm Oversize
