Nason >> Nason Piston & pin set - 4P1066-STD

Nason Piston & pin set - 4P1066-STD

Part
Nason logo

Nason Piston & pin set - 4P1066-STD

$212.36

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 75.50mm
Size: Std
Head Type: Dish Top with 2 Valve Reliefs
Piston Type: Cast
Length: 49.60mm
Comp Height: 28.60mm - 1.60mm
Pin Size: 18.00mm x 56.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.50mm
Oil Ring Width: 2.80mm
Ring Set: 2C4884

Description

Replaces 4MKRY8076
