Nason Piston & pin set - 4P1072-STD

Part

Nason Piston & pin set - 4P1072-STD

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	76.50mm
Size:	Std
Head Type:	Dish Top with 2 Valve Reliefs
Piston Type:	Cast
Length:	50.40mm
Comp Height:	28.40mm - 0.75mm
Pin Size:	18.00mm x 47.30mm
Pin Type:	Press Fit
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.20mm
2nd Ring Width:	1.50mm
Oil Ring Width:	2.50mm
Ring Set:	2C5154
