Nason >> Nason Piston & pin set - 4P1121-1.00

Nason Piston & pin set - 4P1121-1.00

Part
Nason logo

Nason Piston & pin set - 4P1121-1.00

$366.80

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 89.00mm
Size: 1.00mm / .040"
Head Type: Dish Top with 2 Valve Reliefs
Piston Type: Cast
Length: 54.90mm
Comp Height: 32.00mm - 4.10mm
Pin Size: 20.00mm x 57.00mm
Pin Type: Full Floating
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.20mm
Oil Ring Width: 2.50mm
Ring Set: 2C5099

Description

X-Trail T30

Anodized Head, Top & 2nd Ring Lands

Replaces 4KRY8005
