Nason >> Nason Piston & pin set - 4P1200-0.50

Nason Piston & pin set - 4P1200-0.50

Part
Nason logo

Nason Piston & pin set - 4P1200-0.50

Out Of Stock

Specifications
Size: 0.50mm Oversize
Ring Set: 2M6157 or 6157
Oil Ring Width: 4.00mm
2nd Ring Width: 2.00mm
Top Ring Width: 2.00mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 22.00mm x 78.00mm
Comp Height: 37.00mm
Length: 80.00mm
Piston Type: Cast
Head Type: Flat Top
Size: 0.50mm / .020"
Std Bore Size: 87.00mm
Piston Set: 4 x Piston & Pins

Description
