Nason >> Nason Piston & pin set - 4P1205-1.00

Nason Piston & pin set - 4P1205-1.00

Part
Nason logo

Nason Piston & pin set - 4P1205-1.00

$238.10

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 87.20mm
Size: 1.00mm / .040"
Head Type: Dish Top
Piston Type: Cast
Length: 71.00mm
Comp Height: 41.00mm - 1.60mm
Pin Size: 20.00mm x 62.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 2.00mm
2nd Ring Width: 2.50mm
Oil Ring Width: 4.00mm
Ring Set: 2C6830 or 6830
