Nason >> Nason Piston & pin set - 4P1215-0.50

Nason Piston & pin set - 4P1215-0.50

Part
Nason logo

Nason Piston & pin set - 4P1215-0.50

$142.03

Specifications
Size: 0.50mm Oversize
Ring Set: 2M4219 or 4219
Oil Ring Width: 4.00mm
2nd Ring Width: 1.50mm
Top Ring Width: 1.50mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Full Flaoting
Pin Size: 22.00mm x 66.00mm
Comp Height: 35.40mm - 4.30mm
Length: 68.00mm
Piston Type: Cast
Head Type: Dish Top with 4 Valve Reliefs
Size: 0.50mm / .020"
Std Bore Size: 86.00mm
Piston Set: 4 x Piston & Pins

Description

Full Floating Pin 1994 to 1997
