Nason Piston & pin set - 4P1236-1.00

Part

Nason Piston & pin set - 4P1236-1.00

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	76.50mm
Size:	1.00mm / .040"
Head Type:	Dish Top
Piston Type:	Cast
Length:	48.40mm
Comp Height:	28.60mm - 4.10mm
Pin Size:	18.00mm x 54.50mm
Pin Type:	Press Fit
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.50mm
2nd Ring Width:	1.50mm
Oil Ring Width:	3.00mm
Ring Set:	2C4819 or 4819
Size:	1.00mm Oversize
