Nason Piston & pin set - 4P1249-1.00

Part

Nason Piston & pin set - 4P1249-1.00

Out Of Stock

Specifications
Size:	1.00mm Oversize
Ring Set:	2C6154
Oil Ring Width:	4.00mm
2nd Ring Width:	1.50mm
Top Ring Width:	1.20mm
Piston to Bore:	See Label on Box
Skirt Coating:	No
Pin Type:	Press Fit
Pin Size:	20.00mm x 65.00mm
Comp Height:	29.00mm - 2.20mm
Length:	61.00mm
Piston Type:	Cast
Head Type:	Dish Top with 1 Valve Relief
Size:	1.00mm / .040"
Std Bore Size:	77.00mm
Piston Set:	4 x Piston & Pins

Description

Single Carby Model
