Nason >> Nason Piston & pin set - 4P1249-STD

Nason Piston & pin set - 4P1249-STD

Part
Nason logo

Nason Piston & pin set - 4P1249-STD

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 77.00mm
Size: Std
Head Type: Dish Top with 1 Valve Relief
Piston Type: Cast
Length: 61.00mm
Comp Height: 29.00mm - 2.20mm
Pin Size: 20.00mm x 65.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.50mm
Oil Ring Width: 4.00mm
Ring Set: 2C6154

Description

Single Carby Model

Replaces 4KRY8049
