Nason >> Nason Piston & pin set - 4P1251-0.50

Nason Piston & pin set - 4P1251-0.50

Part
Nason logo

Nason Piston & pin set - 4P1251-0.50

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 77.50mm
Size: 0.50mm / .020"
Head Type: Dish Top with 2 Valve Relief
Piston Type: Cast
Length: 61.00mm
Comp Height: 31.00mm - 2.80mm
Pin Size: 20.00mm x 65.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.50mm
2nd Ring Width: 1.50mm
Oil Ring Width: 2.80mm
Ring Set: 2C6140 or 6140

Description

Replaces 4KRY8052
