Nason Piston & pin set - 4P1252-1.00

Part

Nason Piston & pin set - 4P1252-1.00

Out Of Stock

Specifications
Size:	1.00mm Oversize
Ring Set:	2M6151 or 6151
Oil Ring Width:	4.00mm
2nd Ring Width:	1.50mm
Top Ring Width:	1.50mm
Piston to Bore:	See Label on Box
Skirt Coating:	No
Pin Type:	Press Fit
Pin Size:	19.00mm x 62.00mm
Comp Height:	32.50mm - 9.41mm
Length:	62.50mm
Piston Type:	Cast
Head Type:	Dish Top with 2 Valve Relief
Size:	1.00mm / .040"
Std Bore Size:	76.00mm
Piston Set:	4 x Piston & Pins
