Nason >> Nason Piston & pin set - 4P1256-1.00

Nason Piston & pin set - 4P1256-1.00

Part
Nason logo

Nason Piston & pin set - 4P1256-1.00

$134.46

Specifications
Size: 1.00mm Oversize
Ring Set: 2M4217 or 4217
Oil Ring Width: 4.00mm
2nd Ring Width: 1.50mm
Top Ring Width: 1.50mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 22.00mm x 66.00mm
Comp Height: 33.40mm - 4.20mm
Length: 70.30mm
Piston Type: Cast
Head Type: Dish Top with 2 Valve Relief
Size: 1.00mm / .040"
Std Bore Size: 84.00mm
Piston Set: 4 x Piston & Pins
