Nason >> Nason Piston & pin set - 4P1256-STD

Nason Piston & pin set - 4P1256-STD

Part
Nason logo

Nason Piston & pin set - 4P1256-STD

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 84.00mm
Size: Std
Head Type: Dish Top with 2 Valve Relief
Piston Type: Cast
Length: 70.30mm
Comp Height: 33.40mm - 4.20mm
Pin Size: 22.00mm x 66.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.50mm
2nd Ring Width: 1.50mm
Oil Ring Width: 4.00mm
Ring Set: 2M4217 or 4217

Description

Replaces 4MKRY2734 4RP6734
