Nason >> Nason Piston & pin set - 4P1260-0.50

Nason Piston & pin set - 4P1260-0.50

Part
Nason logo

Nason Piston & pin set - 4P1260-0.50

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 87.00mm
Size: 0.50mm / .020"
Head Type: Dish Top with 4 Valve Reliefs
Piston Type: Cast
Length: 71.80mm
Comp Height: 35.50mm - 2.30mm
Pin Size: 21.00mm x 72.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.50mm
2nd Ring Width: 1.50mm
Oil Ring Width: 4.00mm
Ring Set: 2M6149 or 6149

Description

35.50mm Comp Height

Replaces 4MKRY2959
