Nason >> Nason Piston & pin set - 4P1268-1.00

Nason Piston & pin set - 4P1268-1.00

Part
Nason logo

Nason Piston & pin set - 4P1268-1.00

$225.23

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 80.50mm
Size: 1.00mm / .040"
Head Type: Flat Top
Piston Type: Cast
Length: 44.70mm
Comp Height: 24.10mm
Pin Size: 18.00mm x 55.00mm
Pin Type: Press Fit
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.20mm
Oil Ring Width: 2.00mm
Ring Set: 2C5185
Size: 1.00mm Oversize

Description

Suits Z18XE & X18XE1
