Nason >> Nason Piston & pin set - 4P1270-1.00

Nason Piston & pin set - 4P1270-1.00

Part
Nason logo

Nason Piston & pin set - 4P1270-1.00

Out Of Stock

Specifications
Size: 1.00mm Oversize
Ring Set: 2C5184
Oil Ring Width: 2.50mm
2nd Ring Width: 1.20mm
Top Ring Width: 1.20mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 20.00mm x 52.00mm
Comp Height: 28.30mm - 1.30mm
Length: 51.30mm
Piston Type: Cast
Head Type: Dish Top with 2 Valve Reliefs
Size: 1.00mm / .040"
Std Bore Size: 75.50mm
Piston Set: 4 x Piston & Pins
