Nason >> Nason Piston & pin set - 4P1272-0.50

Nason Piston & pin set - 4P1272-0.50

Part
Nason logo

Nason Piston & pin set - 4P1272-0.50

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 87.00mm
Size: 0.50mm / .020"
Head Type: Dish Top with 2 Valve Reliefs
Piston Type: Cast
Length: 59.00mm
Comp Height: 28.00mm - 1.90mm
Pin Size: 22.00mm x 62.00mm
Pin Type: Press Fit
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.20mm
Oil Ring Width: 2.00mm
Ring Set: 2C5148

Description

Replaces 4MKRY8004

Does Not Suit Great Wall.
