Nason Piston & pin set - 4P1275-0.50

Part

Nason Piston & pin set - 4P1275-0.50

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	86.50mm
Size:	0.50mm / .020"
Head Type:	Dome Top with 3 Valve Reliefs
Piston Type:	Cast
Length:	67.00mm
Comp Height:	35.00mm + 0.20mm
Pin Size:	22.00mm x 62.00mm
Pin Type:	Press Fit
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	1.20mm
2nd Ring Width:	1.50mm
Oil Ring Width:	3.00mm
Ring Set:	2C4783
Size:	0.50mm Oversize

Description

22mm Piston Pin
