Nason >> Nason Piston & pin set - 4P1282-1.00

Nason Piston & pin set - 4P1282-1.00

Part
Nason logo

Nason Piston & pin set - 4P1282-1.00

Out Of Stock

Specifications
Size: 1.00mm Oversize
Ring Set: 2C4947
Oil Ring Width: 3.00mm
2nd Ring Width: 1.20mm
Top Ring Width: 1.20mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Full Floating
Pin Size: 20.00mm x 50.00mm
Comp Height: 32.10mm - 6.50mm
Length: 51.60mm
Piston Type: Cast
Head Type: Dish Top with 2 Valve Reliefs
Size: 1.00mm / .040"
Std Bore Size: 79.00mm
Piston Set: 4 x Piston & Pins

Description

Anodized Head, Top & 2nd Ring Lands
