Nason Piston & pin set - 4P1289-STD

Part

Nason Piston & pin set - 4P1289-STD

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	73.00mm
Size:	Std
Head Type:	Dish Top with 4 Valve Reliefs
Piston Type:	Cast
Length:	49.30mm
Comp Height:	26.20mm - 4.60mm
Pin Size:	18.00mm x 54.00mm
Pin Type:	Press Fit
Skirt Coating:	Yes
Piston to Bore:	See Label on Box
Top Ring Width:	1.00mm
2nd Ring Width:	1.00mm
Oil Ring Width:	2.00mm
Ring Set:	2C5253
